How to build your own sheet metal brake
click here for more images
download now sheetmetal brake plans download, view and print plans on your pc. Easily build your own sheet metal brake with these plans
photos for step by step construction. (these are just a few examples of the photos included with the plans)
in this video i show how to build a metal brake with a 72+ inch working capacity. The unit as shown is approximately 82″ tip to tip, has a working surface height of 33.5″ and has a clearance between hinges of approximately 74″. The metal being bent at the end of the video is a 60″ scrap of .040 (1mm) 5052 aluminum. The concept can be scaled up or down to accommodate your needs. This is a simple design that can be built in an evening. I show how to square the brake as well as how to build inexpensive, durable hinges that will handle the stress of bending. A comparable commercial brake would cost $4000+. This can be built with $150 in steel at 2013 pr…read more detail
